Proportional pressure reducing valve
Proportional pressure reducing valve Proportional pressure reducing valve
TYPE CODE PERFORMANCE SPECIFICATIONS
2
M V P PU10 - - / - # Oil viscosity u = 30 mm /s
Pressure reducing valve p = f (Q) Pressure volume flow characteristics p = f (Q) Pressure volume flow characteristics
red
red
Pilot operated Maximal adjustable pressure Minimal adjustable pressure
*Consumer resistance depending on the system
Proportional p [bar] p [bar]
400 K0434_1 40 K0443_4 a: P N red = 160/200/275/350 bar b: P N red = 20/63/100 bar
Screw-in cartridge 7/8“ - 14 UNF a
P N red = 350 bar
300 30
Nominal pressure range p N red 20 bar 20 200 bar 200 P N red = 275 bar b
63 bar 63 275 bar 275 200 P N red = 200 bar 20
100 bar 100 350 bar 350
160 bar 160 100 P N red = 100 bar 10 ∗
P N red = 63 bar
0 P N red = 20 bar 0
Nominal voltage U 12 VDC G12
N 60 40 20 0 20 40 60 60 40 20 0 20 40 60
24 VDC G24 A T Q [l/min] P A A T Q [l/min] P A
without coil X5
Slip-on coil Metal housing round W
Metal housing square M
p = f (n) Pressure adjustment characteristics Q = f (p) Leakage volume flow characteristic
Connection execution Connector socket EN 175301 - 803 / ISO 4400 D red Measured at Q = 0 l/min (static) L A (1) → T (3) (pressure in P (2) = 350 bar)
Connector socket AMP Junior - Timer J
3
Connector Deutsch DT04 - 2P G p [bar] Q [cm /min]
400 K0761 1000 K0760_3
Sealing material NBR P N red = 350 bar 800
FKM (Viton) D1 300 P N red = 275 bar
600
200 P N red = 200 bar
Manual override Manual override HB4,5 P N red = 160 bar 400
Screw plug HB0 100 P N red = 100 bar
P N red = 63 bar 200
Design index (subject to change) 0 P N red = 20 bar 0
2.3-672 0 10 20 30 40 0 60 70 80 90 100 l [%] 0 50 100 150 200 250 300 350 p [bar]
P N red = 20/63/100 bar
P N red = 160/200/275/350 bar
GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS
Designation Proportional pressure reducing valve Working pressure p = 400 bar
max
Construction Pilot operated Nominal pressure P N red = 20; 63; 100; 160; 200; 275; 350 bar
Mounting Screw-in cartridge construction range
Nominal size 7 ⁄8 “-14 UNF according to Wandfluh Volume flow range Q = 0…60 l/min
standard Leakage oil See characteristics ACCESSORIES MANUAL OVERRIDE
Actuation Proportional solenoid Hysteresis ≤ 4 % at optimal dither signal Proportional amplifier Register 1.13 HB4,5
Ambient temperature -25…+70 °C Repeatability ≤ 2 % at optimal dither signal Electric plug B (black) Article no. 219.2002 Optionally: Screw plug (HB0), no actuation possible
Weight 0,53 kg Fluid Mineral oil, other fluid on request Technical explanations Data sheet 1.0-100
MTTFd 150 years Viscosity range 12 mm /s…320 mm /s Filtration Data sheet 1.0-50
2
2
Temperature range -25…+70 °C (NBR)
fluid -20…+70 °C (FKM)
ELECTRICAL SPECIFICATIONS Contamination Class 18 / 16 / 13
efficiency
Protection class Connection execution D: IP65
Connection execution J: IP66 Filtration Required filtration grade ß 6…10 ≥ 75,
Connection execution G: IP67 and IP69K see data sheet 1.0-50 SURFACE TREATMENT SEALING MATERIAL
Relative duty factor 100 % DF ◆ The cartridge body, the slip-on coil and the armature tube are NBR or FKM (Viton) as standard, choice in the type code
Standard nominal 12 VDC, 24 VDC zinc-nickel coated
voltage
Limiting current at I = 1320 mA (U = 12VDC)
N
G
50 °C I = 660 mA (U = 24VDC)
G N
Note! Other electrical specifications see data sheet 1.1-173
(slip-on coil W) and 1.1-174 (slip-on coil M)
