Proportional spool valve
                                                                                     Proportional spool valve                                                                                                     Proportional spool valve


       GENERAL SPECIFICATIONS                              ACTUATION                                                               PERFORMANCE SPECIFICATIONS
       Designation        Proportional spool valve          Actuation          Proportional solenoid, wet pin push                 Oil viscosity u = 30 mm /s
                                                                                                                                                    2
       Construction       Direct operated                                      type, pressure tight                                 Q = f (p)  Volume flow pressure characteristics      Q = f (p)  Volume flow pressure characteristics
       Mounting           Flange construction               Execution          P29V (Data sheet 1.1-90)                                       I = I                                                I = I
                                                                                                                                                 G
                                                                                                                                                                                                      G
       Nominal size       NG3-Mini according to Wandfluh    Connection         Connector socket EN 175301 – 803                               ACB-S, AC1-S, CB2-S                                  ADB-V, AD1-V, DB2-V
                          standard
       Actuation          Proportional solenoid                                                                                       12 Q [l/min]                                         12 Q [l/min]
                                                                                                                                         K1189
                                                                                                                                                                                              K1190
       Ambient temperature  -25…+70 °C                                                                                                10                                    Q N = 5 l/min  10
                          if >50 °C, I  is only conditionally                                                                          8                                                    8                                   Q N = 5 l/min
                                 G
                          achievable                                                                                                   6                                                    6                                   Q N = 2 l/min
       Weight             0,5 kg (1 solenoid)                                                                                          4                                    Q N = 2 l/min   4                                   Q N = 1 l/min
                                                                                                                                                                            Q N = 1 l/min
                          0,65 kg (2 solenoids)                                                                                        2                                                    2
       MTTFd              150 years                                                                                                    0                                                    0
                                                                                                                                        0    50  100  150  200  250  300  350 p [bar]        0    50  100  150  200  250  300  350 p [bar]

       ELECTRICAL SPECIFICATIONS                           HYDRAULIC SPECIFICATIONS
                                                                                                                                    ∆p = f (Q)  Volume flow pressure characteristics     ∆p = f (Q)  Volume flow pressure characteristics
       Protection class   IP65                              Working pressure   p   = 350 bar (p  < 20 bar)                                    I = I                                                I = I
                                                                                           T
                                                                                max
                                                                                                                                                 G
                                                                                                                                                                                                      G
       Relative duty factor  100 % DF                                          p   = 315 bar (p  > 20 bar)                                    ACB-S, AC1-S, CB2-S                                  ADB-V, AD1-V, DB2-V
                                                                                           T
                                                                                max
       Standard nominal   12 VDC, 24 VDC                    Tank pressure      p  max = 100 bar                                        p [bar]                                              p [bar]
                                                                                T
       power                                                Maximum volume flow  Q   = 10 l/min, see characteristics
                                                                                 max                                                  60  K1191                                            60  K1192
       Limiting current at  I  = 540 mA (U  = 24VDC)        Nominal volume flow  Q  = 1 l/min, 2 l/min, 5 l/min                       50     Q  = 1 l/min  Q N  = 2 l/min  Q  = 5 l/min    50     Q  = 1 l/min  Q N  = 2 l/min  Q  = 5 l/min
                                                                                                                                              N
                                                                                                                                                                                                   N
                                                                                                                                                                            N
                                                                                N
                                    N
                           G
       50 °C              I  = 1'080 mA (U  = 12VDC)        Leakage oil        See characteristics                                                                                                                               N
                           G         N                                                                                                40                                                   40
                                                            Hysteresis         ≤ 5 % at optimal dither signal                         30                                                   30
                                                            Fluid              Mineral oil, other fluid on request                    20                                                   20
                                                            Viscosity range    12 mm /s…320 mm /s                                     10                                                   10
                                                                                   2
                                                                                            2
                                                            Temperature range   -25…+70 °C (NBR)                                       0  0    2      4      6      8     10  Q [l/min]     0  0    2      4      6     8      10  Q [l/min]
                                                            fluid              -20…+70 °C (FKM)
                                                            Contamination      Class 18 / 16 / 13
                                                            efficiency
                                                            Filtration         Required filtration grade ß 6…10 ≥ 75,               Q = f (I)  Volume flow adjustment characteristics    Q = f (I)  Volume flow adjustment characteristics
                                                                               see data sheet 1.0-50                                          ∆p = 10 bar                                          ∆p = 10 bar
                                                                                                                                              ACB-S, AC1-S, CB2-S                                  ADB-V, AD1-V, DB2-V
                                                                                                                                       Q [l/min]                                           Q [l/min]
       STANDARDS                                           SEALING MATERIAL                                                           6 5  K1193                           Q  = 5 l/min    6  K1194                            Q  = 5 l/min
                                                                                                                                                                                           5
                                                                                                                                                                                                                                N
       Mounting interface   Wandfluh standard              NBR or FKM (Viton) as standard, choice in the type code                    4                                     N              4
       Solenoids            DIN  VDE 0580                                                                                             3                                                    3
       Connection execution D  EN 175301 – 803                                                                                        2                                    Q  = 2 l/min    2                                   Q N  = 2 l/min
                                                                                                                                                                            N
       Protection class     EN 60 529                                                                                                 1                                    Q  = 1 l/min    1                                   Q N  = 1 l/min
                                                                                                                                                                            N
       Contamination efficiency  ISO 4406                                                                                             0                                                    0
                                                                                                                                        0   10  20  30  40 50 60 70 80 90  100 I    [%]     0   10  20  30  40 50 60 70 80 90  100 I    [%]

                                                                                                                                    Q  = f (p)  Leakage volume flow characteristics
       SURFACE TREATMENT                                   INSTALLATION NOTES                                                        L
                                                                                                                                       Q [cm /min]
                                                                                                                                           3
       ◆  The valve body is painted with a two component paint  Mounting type  Flange mounting                                        80  K1195
       ◆  The solenoid and the cover are re zinc-nickel coated                 3 fixing holes for socket head screws                  70
       ◆  The socket head screws are zinc coated                               M4 x 30                                                60
                                                                                                                                      50
                                                            Mounting position  Any, preferably horizontal                             40
                                                                                                                                      30
                                                            Tightening torque  M = 2,6 Nm (quality 8.8) Fixing screws                 20
                                                                                D
                                                                                                                                      10
                                                           Note!    The length of the fixing screw depends on the base                 0
                                                                    material of the connection element.                                 0    50  100  150  200  250  300  350 p [bar]

                         www.wandfluh.com  Illustrations are not binding  Data subject to change  2/4  Edition: 20 05  1.10-66 E                      www.wandfluh.com  Illustrations are not binding  Data subject to change  3/4  Edition: 20 05  1.10-66 E
