Throttle valve
Throttle valves

Throttle valve
Screw-in cartridge M18x1,5
• Q N max = 30 l/min ISO 7789
• Q max = 40 l/min
• p = 350 bar
max

DESCRIPTION FUNCTION APPLICATION
Manually adjustable, M18x1,5 screw-in cart- A fine tread on the adjustable throttle reveals Throttle valves can be used anywhere where
ridge throttle valve in accordance with cavity an annular gap. The adjusted throttle cross- volume flows can be infinitely controlled in both
ISO 7789. The cartridge body made of steel is section produces a pressure drop which de- directions without taking pressure fluctuations
galvanized and therefore rust-protected. termines the volume flow. The volume flow is into account. Stepped tools are available for
zero when the throttle is screwed in (the metal making the receptacle bores in steel and alu-
sealing edge seals completely). The valve flow minium (hire or purchase). Please refer to the
is bidirectional. data sheets in register 2.13.

TYPE CODE
DN I PM18 - 30 #

Throttle valve
Type of adjustment
Screw-in cartridge M18x1,5
Nominal volume flow rate Q N 30 l/min
Design-Index (Subject to change)

GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS
Description Throttle valve Fluid Mineral oil, other fluid on request
Construction Screw-in cartridge for cavity Contamination efficiency ISO 4406:1999,
acc. to ISO 7789 class 20/18/14…21/19/15
Mounting Screw-in thread M18x1,5 Required filtration grade (ß 10…25 ≥ 75)
Ambient temperature -20…+50 °C (refer to data sheet 1.0-50/2)
Mounting position any Viscosity range 12mm /s…320mm /s
2
2
Fastening torque M = 30 Nm Fluid temperature -20…+70 °C
D
Weight m = 0,11 kg Peak pressure p max = 350 bar
Volume flow direction 1 ↔ 2 Nominal volume flow rates Q = 30 l/min
N
Q at 10 bar valve pressure loss
N
Max. volume flow Q max = 40 l/min
Leakage volume flow Almost leak free with closed restrictor

SYMBOL MECHANICAL ACTUATION
Screw adjustment with fork wrench and Allen key
Control storke S = 4,5 mm
1 2 Control angle α b b = 1620° / 4,5 turns

s 4
Wandfluh AG Ø 17 Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 2.4-512E 1/2
CH-3714 Frutigen Edition 11 26
s 17
