Proportional pressure reducing valve Proportional pressure reducing valve
Proportional pressure relief valve

DIMENSIONS HYDRAULIC CONNECTION Proportional pressure reducing cartridge
Cavity drawing according to Wandfluh standard ◆ pilot operated M42 x 2
◆ Q = 250 l/min ISO 7789
max
max
s30 7/8"-14UNF-2A 7/8"-14 UNF-2B ◆ p = 400 bar
= 350 bar
p
◆
15 N red max
76.8 MD=5.5Nm (3) (2) (3)
37.2
(1)
W = (2)
DESCRIPTION APPLICATION
12 17 10 18 50 70 60 80 90 Pilot operated proportional pressure reducing valve in screw-in The electrical remote control in conjunction with process controls
MD=5Nm (1) cartridge construction for cavity according to ISO 7789. Proportio- allows economical solutions with repeatable processes. The
86.8 47 (1)
nally to the solenoid current, the solenoid force and the pressure in screw -in cartridge is perfectly suitable for installation in control
140
Attention! For detailed cavity drawing and cavity tools see data port A (1) rise. The valve functions practically independently of the blocks. For machining the cartridge cavity in steel and aluminum
sheet 2.13-1045 pressure in port P (2). Pressure increase in the consumer port A (1) blocks, cavity tools are available (hire or purchase). Please refer to

to above the adjusted value, e.g. through an active consumer, is the data sheets in register 2.13.

15 avoided by discharging excess oil to the tank T (3). With the sole-
MD= 9.5Nm noid deenergised, the oil flows freely from port P (2) to consumer
74.8 port A (1). For the control, Wandfluh proportional amplifiers are
35 available (see register 1.13).

M =

10

PARTS LIST

Position Article Description
10 206.2… W.S37 / 19 x 50 SYMBOL ACTUATION
260.5… M.S35 / 19 x 50
Actuation Proportional solenoid, wet pin push
12 154.2700 Knurled nut (A) 1 type, pressure tight
15 253.8000 HB4,5 manual override Execution W.S37 / 19 x 50 (Data sheet 1.1-173)
239.2033 HB0 Screw plug
M.S35 / 19 x 50 (Data sheet 1.1-174)
17 160.2187 O-ring ID 18,72 x 2,62 (NBR) Connection Connector socket EN 175301 – 803
160.6187 O-ring ID 18,72 x 2,62 (FKM) (P) 2 (T) 3 Connector socket AMP Junior-Timer
18 160.2170 O-ring ID 17,17 x 1,78 (NBR) Connector Deutsch DT04 – 2P
160.6172 O-ring ID 17,17 x 1,78 (FKM)
50 160.2188 O-ring ID 18,77 x 1,78 (NBR)
160.6188 O-ring ID 18,77 x 1,78 (FKM)
60 160.2140 O-ring ID 14,00 x 1,78 (NBR)
160.6141 O-ring ID 14,00 x 1,78 (FKM)
70 049.8177 Back-up ring PTSM rd 12,4 x 15,3 x 1,4
80 160.2120 O-ring ID 12,42 x 1,78 (NBR)
160.6124 O-ring ID 12,42 x 1,78 (FKM)
90 049.8166 Backup ring PTSM rd 10,8 x 13,7 x 1,4
STANDARDS INSTALLATION NOTES
Cartridge cavity ISO 7789 Mounting type Screw-in cartridge M42 x 2
Solenoids DIN VDE 0580 Mounting position Any, preferably horizontal
Connection execution D EN 175301 – 803 Tightening torque M = 100 Nm Screw-in cartridge
D
Protection class EN 60 529 M = 5 Nm knurled nut
D
Contamination ISO 4406 M = 9,5 Nm HB0
D
efficiency M = 5,5 Nm HB4,5
D

Wandfluh AG Postfach CH-3714 Frutigen
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 sales@wandfluh.com

www.wandfluh.com Illustrations are not binding Data subject to change 4/4 Edition: 17 49 2.3-673 E www.wandfluh.com Illustrations are not binding Data subject to change 1/4 Edition: 18 47 2.3-690 E
