Amplifier for direct assembly on the valve
Description
Compact amplifier for direct mounting on the solenoid. Pluggable on solenoids according to DIN EN 175301-803, type A. Protection class of the amplifier is IP 65. For 1 or 2 proportional solenoids. Setpoint signal type switchable via PASO2 parametrisation software (voltage/current).
Application
The amplifier is particularly suitable for controlling proportional valves. The applications are found in both industrial and mobile hydraulics for the smooth and controlled operation of hydraulic drives. The M12 plug allows easy connection using standard M12 cables.
Key facts
Digital amplifier electronics PDS1
- for 1 or 2 proportional solenoids with DIN plug
- protection class IP 65
- analogue setpoint signal 0..+/-10V / 0/4..20mA
- M12 connector plug
- adjustable via USB by means of new Wandfluh PASO2
