Solenoid
                                                                                                   Solenoids                                                                                                                    Solenoids

       CHARACtERIStICS                                                                  12VDC      24VDC                           Solenoid SIN35V
       Static pressure tightness   350 bar (seal diameter of valve    Totale stroke  (mm)   2,5    2,5                             to VDE 0580
                             max. 15 mm)                    Working stroke       (mm)   1          1                               Plug plate to ISO 4400 / DIN 43650
       Coil winding insulation class   H                    Rated force        (N)      29         29
       Connection / Power supply   Over device plug connection to    Hysteresis of rated force   (%)   5,5  5,5                    Protection class IP65
                             ISO 4400 / DIN 43650, (2P+E),    Hysteresis of rated current  (%)   5,5  5,5
                             other connections on request   Nom. linearity deviation    (%)   4,5  4,5
       Protection class EN 60 529   IP65                    Rated resistance   (Ω)      7,2        31
       Relative duty factor   100 %                         Rated current       (A)     1,08       0,54
       Reference temperature   50 °C                        Limiting current       (A)   1,08      0,54                            DESCRIPtION                        fuNCtION                           APPLICAtION
       Seal                  Viton, other on request        Linearity current  (A)      0,2        0,1                             The SIN35V is a switching solenoid. Its design   When the solenoid is energised with the speci-  Essential for hydraulic directional and poppet
       Fluid                 Mineral oil, other fluid on request  Actuation current  (A)   0,02    0,01                            corresponds to VDE standard 0580. The steel   fied nominal voltage, the armature moves from   valves. Because of the risk of overheating, the
       Mounting screws       4 x M3 (Quality 8.8)           Nominal wattage    (W)      8,1        8,8                             housing is zinc coated as a standard. Static   the starting position of its stroke (s = 3,2 mm)   solenoid must never be used separately. The
       Housing               Zinc coated steel housing, other    Performance limit  (W)   13       13                              pressure tightness is 160 bars. All o-rings are   to the end position (s = 0 mm). The switching   lenght of the fixing screws depends on the base
                             surface treatments on request  Number of windings  (-)     645        1'310                           Viton.  The  solenoids  are  fixed  to  the  valve   time is essentially dependent on the application.   material of the body. An o-ring is used for the
                                                            Inductivity        (mH)     12         45                              with four screws. Depending on the intended   The power stroke characteristics are designed   valve seal. Information on screws and o-rings
                                                            Armature weight    (kg)     0,014      0,014                           use, the solenoid can be supplied with a plug   to suit the requirements of hydraulic valves. AC   will be found in the data sheets relating to the
                                                            Solenoid weight       (kg)   0,21      0,21                            screw, or with integrated manual override. The   versions include an electronic rectifier integrated   valves concerned. Before changing the plug
                                                                                                                                   connector plate corresponds to ISO 4400 and   into the connector plate. In this way maximum   screw  or  the  screw  with  integrated  manual
                                                                                                                                   DIN 43650.                         performance is assured.            override, care must be taken to ensure that the
                                                                                                                                                                                                         solenoid is not under pressure. Risk of injury!
                                                                                                                                                                                                         The maximum operating pressure is determin-
                                                                                                                                                                                                         ded by the valve actually used.
                                                                                                                                                                      tyPE CODE
       PERfORMANCE
       F = f (s)   Force-stroke characteristics             F = f (I)   Force-current characteristics                                                                                                            SI  N  35  V  -   -   #
                                                                                                                                                                      Solenoid
         F [N]                                                F [N]                                                                                                   Industrial execution
        35  K0110  1.2 l G                                   35  K0111                                                                                                Normal
                                                                                                                                                                      Square 35 mm housing
        30        1.0 l G                                    30                                                                                                       Solenoid completly potted
                                                                                                                                                                      Nominal voltage U         12 VDC     G12
                                                                                                                                                                                   N
                                                                                                                                                                                                24 VDC     G24
                                                             25
        25                                                                                                                                                                                      115 VAC    R115  ∗
                  1.8 l G                                                                                                                                                                       230 VAC    R230  ∗
                                                                                                                                                                      AC= 50 to 60 Hz
        20                                                   20                                                                                                       ∗ Rectifier integrated in the plug plate
                                                                                                                                                                      Other nominal voltages and nominal power on request
                  0.6 l G                                    15
        15                                                                                                                                                            with mounted screw plug (data sheet 1.1-300)   HB0
                                                                                                                                                                      with mounted manual override (data sheet 1.1-300)   HB4,5
                                                             10                                                                                                       with mounted special manual override (data sheet 1.1-310)   H...
        10        0.4 l G
                                                                                                                                                                      Design-Index (Subject to change)
                                                              5
         5
                  0.2 l G
                                                              0                                                                    DImENSIONS
         0
          0    0.5    1    1.5    2   2.5    s [mm]            0     20   40    60    80   100   I    [%]                                                                                                         6,25
                                                                                                G
                                                                                                                                                                                                                      1,25
         =  Working stoke

       ACCESSOIRES                                                                                                                   8 x0,75
       Plug HB0                           Article No. 239.2033                                                                                                    2,9      74                                                  4
                                          data sheet 1.1-300                                                                         M
       Plug with integrated manual override HB4,5    Article No. 253.8000                                                                                            32  45,5                                                     8
                                          data sheet 1.1-300                                                                                                                                          4,5                            12,5

       Plug grey                         Article No. 219.2001
       Plug black                        Article No. 219.2002
                                                                                                                                                    53         2,2
                                                                                                                                                   59,2                                    28
                                                                                                                                                  70                                       35                         9,9*
                                                            Technical explanation see data sheet 1.1-410                           * Solenoid energised (s= 0 mm)


       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-90E 2/2               Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-105E 1/2
       CH-3714 Frutigen                                                                            Edition 07 29                   CH-3714 Frutigen                                                                             Edition 05 01
