3.2 Mobile electronics I/O module CL-449
Mobile electronics
103
• Digital mobile electronics CL-449 Programmable Mobile Electronics
103
• Robust construction with plug-in connection for mobile applications
D 88.9 D
• Protection class IP68
• Multi-functional pin assignment, up to 8 I/Os
• CAN connection
• Freely programmable 4.8
79
39.5
Geprüft
FA
04.05.2016
E Gezeichnet 31.03.2016 BEH E

DESCRIPTION FUNCTION APPLICATION Freigegeben M 1:1 04.05.2016 Gewicht TK
Änderungsbeschrieb
Serie freigegeben
Name Änderungsnr.
Rev.
Datum
Ersetzt durch:
Mobilelektronik I/O Modul
Microcontroller based control with multifunc- The control can be used and programmed as a This mobile electronics is used mainly in the 0.164 kg
Ersatz für:
Format
Dok.-Nr.
0195322
CL-449
A2
tional inputs/outputs of the PME devices family stand alone unit, or as part of a distributed, de- mobile field because of the compact construc- Revision
Art.-Nr.
Dokument darf ohne schriftliche Einwilligung weder kopiert,
DB 1.13-280
00
verwertet noch an Dritte weitergegeben werden.
(Programmable Mobile Electronics). Delivered centralised system architecture. The variably tion, protection class IP67 as well as the ex- Blatt 1 von 1
Zuwiderhandlung ist strafbar und wird gerichtlich verfolgt.
3
2
4
1
5
C:\00_Wandfluh\Verkauf\Dokumentation\Reg1.13\0195322
in a robust and compact plastic housing, it is usable inputs and outputs enable reading and tensive operating temperature range and the
designed for the hard use in working devices controlling sensors and actuators of all kinds. selected plug connection. Customer-specific
and is perfectly suitable for various open loop The free programmability enables maximum requirements can easily be implemented.
and closed loop control tasks. flexibility for the adaptation to any desired
machine function.
CONTENT TYPE CODE
GENERAL SPECIFICATIONS 1 CL-449-100-11-WAG-00 Master I/O Module
ELECTRICAL SPECIFICATIONS 1 CL-449-100-21-WAG-00 Client I/O Module
DIMENSIONS, ASSEMBLY 2 CL-449-101-11-WAG-00 Master I/O Module with 5V sensor supply
ACCESSORIES 2 CL-449-101-21-WAG-00 Client I/O Module with 5V sensor supply
CONNECTOR WIRING DIAGRAM / 3 CL-449-103-11-WAG-00 Master I/O Module with 4 current analog inputs
PIN ASSIGNMENT CL-449-103-21-WAG-00 Client I/O Module with 4 current analog inputs
GENERAL SPECIFICATIONS
Execution Plastic molded housing
Dimensions 103 x 79 x 45 mm (see Dimensions)
Mounting Mounting flange, screwed on
Weight 210 g
Device receptacle Deutsch DTF15-12PA pin header
Mating connector Deutsch DT06-12SA
Working temperature -40…+70°C Note: Mating connector not part of the delivery
MTBF 139 years (Telcordia SR-332)
ELECTRICAL SPECIFICATIONS
Protection Class IP68 Digital Outputs
Supply Voltage 8…32 VDC Number of outputs up to 4
No-load current 23mA at 13.8 V, 13mA at 28 V Protection Short to GND
Short to Battery
Analogue Inputs Overcurrent
Number of inputs up to 4 Pull-up/down 560 Ohm / 1.4 kOhm for diagnostics
Input voltage range 0…5.5 V
Input resistance 57 kOhm DOUT Digital Outputs
Input range current 0…22.1mA maximum current 3.0 A (individual)
Input resistance 201.3 Ohm 2.5 A (grouped)
Resolution 12 bit PWM Pulse Width Modulation Outputs
maximum current 3.0 A (individual)
Digital Inputs 2.0 A (grouped)
number of inputs up to 8 ECC Estimated Current feedback, 0.2–4.1 A / 12 bit
Accuracy ECC +/- 50mA at 2 A
STB switch to battery input
Input resistance 1.4 kOhm Sensor output (only with CL-449-101)
Switching threshold positive >6.5V, negative <3.5V Supply 5 V +/- 5 %, 250 mA
STG Switch To Ground input
Pull-up resistor 560 Ohm to internal 5V CAN 40 kbit/s to 500 kbit/s
Switching threshold positive >3.25V, negative <1.75V
FREQ Frequency Input
Switching threshold positive >3.5V, negative <1.0V
Pull-up resistor 4.7kOhm to internal 5V
Resolution < 5 Hz Software
Frequency Range max. 10 kHz Apart from the programming tools, a software for diagnostics and
(open drain, sinking sensor) error eliminating for the commissioning of the system is available.
Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 1.13-280E 1/3
CH-3714 Frutigen Edition 19 18
