Page 294 - Softbound_Edition_19_en

AK4x10
Spool valve AK4x10

TYPE CODE PERFORMANCE SPECIFICATIONS
A K 4 - # Oil viscosity u = 30 mm /s
2
International standard interface ISO
p = f (Q) Performance limits Q = f (Q) Leakage volume flow characteristics
L
Pneumatically operated per control edge
3
Number of control ports p [bar] J100/ Q [cm /min]
350 K0413 Z100/D103 D101/D102/ 300 K0304
D104/D105
Designation of symbols acc. to table 300 250
250 200
Sealing material NBR 200 150
FKM (Viton) D1 150 100
100
Design index (subject to change) 50 50
1.6-40 0 0 10 20 30 40 50 60 70 80 Q [l/min] 0 0 50 100 150 200 250 300 350 p [bar]
GENERAL SPECIFICATIONS ACTUATION

Designation 4/2-, 4/3-spool valve Actuation Pneumatically operated Δp = f (Q) Pressure drop volume-flow characteristics Volume flow direction
Construction Direct operated Execution Actuation AKI
Mounting Flange construction Pilot pressure p V min = 2.5 bar at p = 20 bar Symbol P - A P - B P - T A - T B - T
T
Nominal size NG10 according to ISO 4401-05 p V min = 5 bar at p = 200 bar 20 p [bar] Z100 / J100 2 2 - 2 2
T
K0414
Actuation Pneumatically operated Control volume V = 10,7 cm 3 D101 / Z101 2 2 - 2 2
Ambient temperature -25…+70 °C (NBR) 15 3 D102 / Z102 2 2 - 1 1
-20…+70 °C (FKM) 10 2 D103 / Z103 2 2 3 2 2
Weight 3,8 kg (1 actuation) 1 D104 / Z104 1 1 - 1 1
4,8 kg (2 actuations) SEALING MATERIAL 5 D105 / Z105 1 1 - 2 2
MTTFd 150 years NBR or FKM (Viton) as standard, choice in the type code 0
0 20 40 60 80 Q [l/min]

HYDRAULIC SPECIFICATIONS MANUAL OVERRIDE
Working pressure p = 350 bar In mechanical control head integrated. Actuation by pressing the pin
max DIMENSIONS
Tank pressure p = 200 bar
T max 4/3-way valve (spring centred) 4/2-way valve (spring reset)
Maximum volume flow Q = 80 l/min, see characteristics
max
SURFACE TREATMENT 4/2-way valve (impulse)
Leakage volume flow See characteristics ◆ The valve body is painted with a two component paint 10.5
Fluid Mineral oil, other fluid on request ◆ The pneumatic actuation, the cover and the socket head screws G1/8" 7 MD= 9.5Nm
2
2
Viscosity range 12 mm /s…320 mm /s are zinc coated 7
Temperature range -20…+70 °C
fluid STANDARDS
Contamination Class 20 / 18 / 14 60 55 60 62
efficiency Mounting interface ISO 4401-05
Filtration Required filtration grade ß 10…16 ≥ 75, Contamination ISO 4406
see data sheet 1.0-50 efficiency 10 40 10 50 20 30
MD= 9.5Nm MD=9.5Nm
57 93 18
225 177
INSTALLATION NOTES ACCESSORIES
HYDRAULIC CONNECTION PARTS LIST
Fixing screws Data sheet 1.0-60
Mounting type Flange mounting
4 fixing holes for Threaded subplates Data sheet 2.9-40 54 Position Article Description
socket head screws M6 x65 Multi-station subplates Data sheet 2.9-70 10 254.5000 Pneumatic actuation AK I
P
Mounting position Any, preferably horizontal Horizontal mounting blocks Data sheet 2.9-110 20 059.2201 Cover
Tightening torque M = 8,9 Nm (screw quality 8.8, Technical explanations Data sheet 1.0-100 A B 1.5 16.8 30 246.3121 Socket head screw M6 x 20 DIN 912
D
zinc-coated) Fixing screws 46 9.7
Hydraulic fluids Data sheet 1.0-50 40 246.3166 Socket head screw M6 x 65 DIN 912
T To
Note! The length of the fixing screw depends on the base Filtration Data sheet 1.0-50 50 160.2140 O-ring ID 14,00 x 1,78 (NBR)
material of the connection element. 20.8
24 Wandfluh AG Postfach CH-3714 Frutigen
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 sales@wandfluh.com

www.wandfluh.com Illustrations are not binding Data subject to change 2/3 Edition: 16 29 1.6-40 E www.wandfluh.com Illustrations are not binding Data subject to change 3/3 Edition: 16 29 1.6-40 E
