Solenoid accessory
Solenoid accessory

Manual Overrides
with spring reset
or combined with spring return and detent

DESCRIPTION FUNCTION APPLICATION
The manual overrides are screwed into the When commissioning a machine or if the po- Both types of manual override can be screwed
solenoid. Two types of overrides are availab- wer supply fails, the solenoid function can be into solenoids with an M8 x 0,75 thread. With
le: one with spring reset and one with spring replaced by operating the manual override. In the manual override it is not possible to bleed
reset plus locking in the switched position. The the case of the type with lock, the solenoid can air from valves. Note: Only restricted use for
housing is made of brass as standard. The pin also be held in the end position. poppet valve.
is made of stainless steel.

CONTENT TYPES

DIMENSIONS ........................................... 1 Manual overrides
Solenoid type Spring reset Detent
Des. Art. no. Des. Art. no.
Square 29-solenoids (NG3)
BSIIIV H1 253.9000 H6 253.9502
SIN29V H1 253.9000 H22 253.9012
SIS29V H1 253.9000 H22 253.9012
PI29V H1 253.9000
Square 35-solenoids (NG4)
BEIIV H1 253.9000 H22 253.9500
SIN35V H1 253.9000 H6 10 253.9502
SIS35V H1 253.9000 H6 253.9502
PI35V H1 253.9000 Ø 1,5
Square 45-solenoids (NG6)
SIN45V Ø 18 Ø 13 H1 253.9000 H19 253.9013
SIS45V H1 253.9000 H19 253.9013
PI45V H1 253.9000
Square 60-solenoids (NG10) M8x0,75
SIN60V H21 253.9015 27 H20 6 x H 253.9014
SIS60V H21 253.9015 H20 253.9014
37
PI60V H21 253.9015
DIMENSIONS
Type with spring reset Type with spring reset plus locking

H
10 10
Ø 1,5 Ø 1,5

Ø 18 Ø 13 Ø 18 Ø 13

M8x0,75 M8x0,75
27 6 x H 27 6 x
37 37

Type x H Type x H PARTS LIST
H Position Article Description
H1 0 max.10 H19 0,3 10 10
H22 -2 10 H20 4 10
Ø 1,5
H6 -1 10 H21 4 max.10 10 160.6076 O-ring ID 7,65x1,78
Ø 18 Ø 13

M8x0,75
Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
6 x
27
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 1.1-310E 1/1
CH-3714 Frutigen 37 Edition 23 01
