Line mount bodies Line mount bodies
Line mount bodies

Line mount body M18x1,5
GeneraL sPeCifiCations sCrew-in CartriDGes instaLLeD
Description Line mount body According to the type the following screw-in cartridges can be installed • for 2-way-valves M22x1,5
Mounting 2 location holes in the line mount bodies: in screw-in cartridge construction
2 tapped holes • p = 400 bar M33x2
Connection Threated connections Type Data sheet no. max
Mounting position see valve data sheet M42x2
Surface protection zinc coated M18x1,5
BV.PM18 2.1-510 VARIATIONS TYPE CODE
BS.PM18 2.1-520 Types
HYDraULC sPeCifiCations BS.PM18-Z36 2.1-522 KG - #
Peak pressure p max = 400 bar BVPPM18 2.3-510 A01 B01 Line mount body made of steel
BDPPM18 2.3-520
CartriDGe CavitY Port size G 3/8“ G38 G 1/2“ G12
G 3/4“ G34 G 1 1/4“ G114
M22x1,5 Cavity thread diameter M18x1,5 18 G 3/8“
BV.PM22 2.1-530 M22x1,5 22 G 1/2“
BVTPM22 2.1-532 M33x2 33 G 3/4“
BVEPM22 2.1-536 M42x2 42 G 1 1/4“
(2) BA.PM22 2.1-540 Variations/Types A01 A01
BK.PM22 2.1-542 B01 B01
BS.PM22-Z36 2.1-543 Design index (subject to change)
(1) BVPPM22 2.3-529
BVPPM22-../ME 2.3-537
BNIPM22 2.3-533
(1) BVBPM22 2.3-536 DIMENSIONS A01 DIMENSIONS B01
BDPPM22 2.3-539 E E
BDPPM22-../ME 2.3-561 2 N 2 N
BDIPM22 2.3-548
type Cavity according to: for detailed cavity drawing BDIPM22-../ME 2.3-562
see data sheet: BDBPM22 2.3-547
M6 M6
M18x1,5 ISO 7789–18–02–0–98 2.13-1001 M33x2
M22x1,5 ISO 7789–22–02–0–98 2.13-1003 BV.PM33 2.1-550 I A I A
M33x2 ISO 7789–33–02–0–98 2.13-1041 BVPPM33 2.3-551 1 L L
BVPPM33-../ME 2.3-553 D
M42x2 ISO 7789–42–02–0–07 2.13-1048 D H K
M42x2 H K
BVPPM42 2.3-590 Ø6,5 B Ø6,5 B
G 1
M
F
G
C
F
CaUtion! C
The performance data refer to the screw-in cartridges only.
The additional pressure drop in the line mount body must
be taken into consideration. TYPE A01
Ordering Size Ports Dimensions (in mm) Wight
code
Technical explanation see data sheet 1.0-100 1 2 M A B C D E F G H I K L N
KGG3818-A01 M18x1,5 G 3/8“ G 3/8“ G 1/4“ 60 30 65 23 17.3 44.5 32.5 8 44 8 30 22 0.75
KGG1222-A01 M22x1,5 G 1/2“ G 1/2“ G 1/4“ 60 45 80 23 22.5 53.5 40 8 44 8 30 32 1.45
KGG3433-A01 M33x2 G 3/4“ G 3/4“ G 1/4“ 80 50 80 32.5 30.5 61.5 50 11 58 10 45 34 1.90
KGG11442-A01 M42x2 G 1 1/4“ G 1 1/4“ G 1/4“ 100 60 100 40 33.5 80 62 11 78 12.5 55 44 3.20

TYPE B01

Ordering Size Ports Dimensions (in mm) Wight
code 1 2 M A B C D E F G H I K L N
KGG1222-B01 M22x1,5 G 1/2“ G 1/2“ 60 45 80 23 22.5 60 40 8 44 8 30 32 1.45

Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no. Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 2.9-200E 2/2 Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 2.9-205E 1/2
CH-3714 Frutigen Edition 14 09 CH-3714 Frutigen Edition 17 01
